Your home electrical panel has only so much capacity. And you realize this only when you plan on installing an EV charger or a similar high-power appliance.
This is especially true if your home has a standard 100 amp service and most of its capacity is already in use by your existing home appliances. It is in this case that your electrician recommends upgrading from 100 amp to 200 amp service.
But how much does it cost to upgrade to 200 amp service?
Well, you can expect to pay anywhere between $3,000 and $6,000 for a standard upgrade. This is the range in which most homeowners pay.
However, if your service upgrade involves trenching, underground work, installing new service conductors, meter work, or utility company involvement, you can expect the cost to go up-to $10,000.
In this blog, I have broken down the cost for 200 amp service upgrade in detail. Also, I have explained how you can save this money and utilize your existing panel capacity.
Sounds interesting?
So, let’s look at things in detail.
Key takeaways
- You can expect to pay between $3,000 and $6,000 for a standard 100 amp to 200 amp service upgrade.
- A 200 amp panel replacement is different from upgrading your entire electrical service to 200 amps.
- Underground service, new meter equipment, service conductors, trenching, and utility work can increase the price.
- You don’t always need 200 amp service just because you’re installing a Level 2 EV charger.
- Get a proper load calculation to see if your existing service has enough capacity for your EV charger.
How much does it cost to upgrade to 200 amp service?
Upgrading your standard 100 amp service to 200 amp costs between $3,000 and $6,000.
However, the final cost depends on the extent of work. For instance, if your home already has enough 200 amp service and you are simply replacing the electrical panel, the cost will be much lower.
But if you are increasing your home’s overall electrical service from 100 amps to 200 amps, you can expect to pay in the mentioned range.
Also, if the work is more complicated and you also need to factor utility cost of panel upgrade, be prepared to pay up-to $10,000.
No More $10k Electrical Panel Upgrade to Charge Your EV at Home
simpleSwitch lets you add a Level 2 EV charger to your home without an expensive electrical panel upgrade. Your EV charges safety without panel overload.
30-day risk-free returns- NEMA-rated
- Works with your existing panel
Overall, here’s the cost of 200 amp service upgrade based on project type:
| Project | Cost |
| 200A panel replacement (you home already have enough panel electrical capacity) | $1,300-$3,000 |
| 100A to 200A service upgrade | $3,000-$6,000 |
| More complicated service upgrades (also involves utility company | $6,000-$10,000 |
| Major underground or utility-related work | More than $10,000 |
What is the difference between 200 amp panel upgrade vs 200 amp service upgrade?
When it comes to the cost for 200 amp service upgrade, you will find the terms panel upgrade and service upgrade are used almost interchangeably.
But let me tell you they are both different things and their cost ranges are also different.
For instance, a 200 amp panel upgrade or panel replacement might mean you are simply installing a new electrical panel while your home already has 200 amp electrical service. In this case the overall cost to upgrade your electrical panel will be between $1,300 and $3,000.
Here, you are simply upgrading the electrical panel hardware while not working on the wiring, trenching, etc.
On the other hand, if you are undertaking a 100 amp to 200 amp service upgrade, you are essentially increasing your home’s service capacity. This involves a lot more work than a simple panel hardware change.
In fact, depending on your home, an electrician will need to replace things like main electrical panel, breaker, service entrance conductors, meter socket or base, weatherhead, grounding and bonding components. Also, this might involve securing permits, electrical department inspections for NEC compliance, and coordination from utility company.
Now, since a licensed electrician takes care of everything end-to-end here, they can charge you between $3,000 and $6,000 for a full service upgrade.
Why is the 100 amp to 200 amp upgrade cost so high?
The cost to upgrade 100 amp to 200 amp service is high mainly because it involves changes to the electrical infrastructure. Not to mention, there is also a permit process, electricity department inspection, and utility coordination involved.
All in all, here’s why the cost to upgrade electrical panel to 200 amps is high:
| Cost driver | Why it adds to the cost |
| New service conductors | Larger conductors are be needed for the higher service |
| Meter socket/base | Existing equipment might not be suitable for 200A |
| Service mast/weatherhead | Might need replacement or modification |
| New panel and breakers | Larger service requires appropriately rated equipment |
| Grounding/bonding | Existing system might need upgrades |
| Permits and inspection | Required by the local jurisdiction as per NEC requirements |
| Underground service | Can require trenching and restoration |
| Utility work | Utility-side changes might be needed |
Overhead vs underground service upgrade: What’s cheaper?
An overhead service is cheaper to upgrade because your electrical can replace the necessary service equipment and conductors without big ticket excavation work.
An underground service upgrade, on the other hand, is much more complicated to upgrade. That’s because new service conductors have to run through a long underground conduit, which triggers trenching, concrete removal, landscaping repairs, or other infrastructure work.
So how much is the price difference exactly?
Well, with an overhead upgrade, you can expect to pay in the lower end of the average service upgrade cost, which is $3,000. In rare cases, this can go up-to $5,000.
But for an underground service upgrade, the cost can easily be in the range of $6,000-$10,000.
Do you really need to upgrade to 200 amp for an EV charger or other high-power appliances?
No, you don’t really need to upgrade to 200 amp service just to install a Level 2 EV charger or similar high-power appliance like a hot tub or induction cooktop.
Yes, a Level 2 EV charger can be a substantial electrical load. And spending on the charger’s configuration, it can require a dedicated circuit capable of supplying 30, 40, 48 amps or more. I can also say the same thing for other high-power appliances.
But if your home already has some high-power appliances, you can simply use a load sharing device like simpleSwitch to share the spare electrical power with the new appliances.
How?
Well, a load sharing device safely shares the spare electrical power from a primary appliance that is not in use to a secondary appliance that needs power.
For instance, if your dryer is the primary appliance and it is not in use, simpleSwitch can share its spare electrical capacity to power your Level 2 EV charger. And whenever you turn the dryer on, it will automatically pause EV charging.
For a few hundred dollars, this can save you all the above 200 amp service upgrade costs.
That’s awesome, isn’t it?
Pro tip: Always ask your electrician to perform a load calculation before agreeing to a service upgrade. That’s because only a load calculation truly determines if an upgrade is needed.
Bonus: Here are a few things to check when you get a 200 amp service upgrade quote
| What to check | Why it is important |
| What is being replaced? | Confirms the scope of the upgrade. |
| Are service conductors included? | Larger conductors might be needed for 200A service. |
| Is meter equipment included? | Replacement might be required for the higher service rating. |
| Are permits and inspections included? | Helps avoid unexpected costs later. |
| Is utility work included? | Utility disconnect/reconnect might increase the cost later if it is not included. |
| Is trenching or restoration required? | Underground work can significantly increase costs. |
| Are code-related repairs included? | Existing issues might need to be fixed before approval. |
| Has a load calculation been performed? | Helps determine whether a 200A upgrade is actually necessary for an EV charger or high-power appliance. |
FAQs about 200 amp service upgrade
How much does it cost to upgrade 100 amp to 200 amp service?
A typical 100 amp to 200 amp service upgrade can cost between $3,000 and $6,000. The actual price will depend on your home’s existing service, equipment, location, labor, permits, and whether utility or underground work is required.
Does an EV charger require 200 amp service?
No. An EV charger does not always require a 200 amp electrical service.
A qualified electrician should first evaluate the home’s existing electrical capacity and the charger’s electrical demand to determine whether the existing service can support it.
Can I install an EV charger without upgrading to 200 amp service?
In some homes, yes. If the existing service has sufficient capacity, a service upgrade might not be necessary.
And even if available capacity is limited, a load sharing device can help share spare electrical capacity from other high-power appliances to charge your EV.
What is the difference between a 200 amp panel upgrade and a 200 amp service upgrade?
A panel upgrade can involve replacing the electrical panel while keeping the home’s existing service capacity.
A 200 amp service upgrade increases the electrical service capacity and might require new service conductors, meter equipment, grounding work, and utility coordination.
No More $10k Electrical Panel Upgrade to Charge Your EV at Home
simpleSwitch lets you add a Level 2 EV charger to your home without an expensive electrical panel upgrade. Your EV charges safety without panel overload.
- 30-day risk-free returns
- NEMA-rated
- Works with your existing panel
Final words
I am sure you now know the cost to upgrade to 200 amp service.
For a typical 100 amp to 200 amp service upgrade, you can expect to pay between $3,000-$6,000. But for more complicated projects that involve underground work and utility coordination, you can expect the bills to increase up-to $10,000, or more.
But you need not spend so much already. You can ask your electrician to first perform a load calculation. Also, ask them about load sharing options and if devices like simpleSwitch can offset the need for service upgrade.
